spAriaUtil

The spAriaUtil API provides methods to show messages on a screen reader.

This API is an angular service that you can use in Service Portal widget client scripts.

sendLiveMessage(String message)

Announce a message to a screen reader.

The sendLiveMessage() method injects text into an aria-live region on the page. The default setting for an aria-live region is assertive, which means that messages are announced immediately. This can annoy and confuse users if used too frequently.

Parameters

Returns

Example

function(spAriaUtil) {
  /* widget controller */

  spAriaUtil.sendLiveMessage('Hello world!');
}

Version: zurich

API Reference – Client Side

ServiceNow provides client-side JavaScript APIs allowing all of you to control aspects of how ServiceNow is displayed and functions within the web browser. This reference lists available classes and methods along with parameters, descriptions, and examples to make controlling the end user experience easier.

spContextManager

Makes data from a Service Portal widget available to other applications and services in a Service Portal page. For example, pass widget data to Agent Chat when it opens in a Service Portal page.

The spContextManager API is an AngularJS service that you can use in Service Portal widget client scripts.

Keys passed to this API are unique per page. For example, if the 'agent-chat' key is already initialized by another widget on the page through the addContext() method, you must use the updateContextForKey() method to update the key’s data. Available keys include: agent-chat: Sends widget data to Agent Chat.

For more information about passing data to Agent Chat, see Configure Agent Chat in Service Portal.

addContext(String key, Object context)

Initializes a key and adds widget data as the value. For example, add data to the ‘agent-chat’ key to make it available to Agent Chat.

Use this method the first time data is added to a specific key on a Service Portal page. If the key is already used by another widget on the page, use the updateContextForKey() method instead.

Parameters

Returns

Example

Pass approval_count to Agent Chat. When a user initiates an Agent Chat conversation from the Service Portal homepage, the system appends &sysparm_approval_count=5 to the Agent Chat iframe URL.

function ($scope, spContextManager) {
    spContextManager.addContext('agent-chat', {
        'approval_count': 5
    });
};

getContext()

Returns each key and associated data object defined by any widget on the page.

Using this method may affect performance. Use this method to understand which keys are initialized on the page and to get their current values. If you know which key you need to access, use the getContextForKey() method instead.

Returns

Example

function ($scope, spContextManager) {
  spContextManager.getContext();
}

getContextForKey(String key, Boolean returnPromise)

Returns the widget data associated with a key.

Parameters

Returns

Example

Pass approval_count to Agent Chat. When a user initiates an Agent Chat conversation from the Service Portal homepage, the system appends &sysparm_approval_count=5 to the Agent Chat iframe URL.

function ($scope, spContextManager) {
  spContextManager.getContextForKey('agent-chat', true).then(function(context) {
    context = context || {};
    context.approval_count = 5;
    spContextManager.updateContextForKey('agent-chat', context);
  });
}

updateContextForKey(String key, Object context)

Sends data to an existing key. For example, if another widget on the page uses the ‘agent-chat’ key to pass data to the Agent Chat configuration, you must update the context of the key rather than using the addContext() method.

Parameters

Returns

Example

Pass approval_count to Agent Chat. When a user initiates an Agent Chat conversation from the Service Portal homepage, the system appends &sysparm_approval_count=5 to the Agent Chat iframe URL.

function ($scope, spContextManager) {
  spContextManager.getContextForKey('agent-chat', true).then(function(context) {
    context = context || {};
    context.approval_count = 5;
    spContextManager.updateContextForKey('agent-chat', context);
  });
}

Version: zurich

API Reference – Client Side

ServiceNow provides client-side JavaScript APIs allowing all of you to control aspects of how ServiceNow is displayed and functions within the web browser. This reference lists available classes and methods along with parameters, descriptions, and examples to make controlling the end user experience easier.

spModal

Shows alerts, prompts, and confirmation dialogs in Service Portal widgets. The spModal class is available in Service Portal client scripts.

The spModal class is a lightweight wrapper for Angular UI bootstrap’s $uibModal. You can use the spModal.open() method to display a widget in a modal dialog.

alert(String message).then(fn)

Displays an alert.

Parameters

Returns

Example

// HTML template
<button ng-click="c.onAlert()" class="btn btn-default">
    Alert
  </button>

// Client script
function(spModal) {
    var c = this;
  c.onAlert = function () {
        spModal.alert('How do you feel today?').then(function (answer) {
            c.simple = answer;
        });
    }
 }

confirm(String message).then(fn)

Displays a confirmation message.

Parameters

Returns

Example

// HTML template
 <button ng-click="c.onConfirm()" class="btn btn-default"> Confirm </button>
<span>{{c.confirmed}}</span>

// Client script
function(spModal) {
  var c = this;
  c.onConfirm = function() {
        c.confirmed = "asking";
        spModal.confirm("Can you confirm or deny this?").then(function(confirmed) {
            c.confirmed = confirmed; // true or false
        })
    }
 }

Example

Confirm with HTML message:

//HTML template
<button ng-click="c.onConfirmEx()" class="btn btn-default">
    Confirm - HTML message
  </button>
  <span>{{c.confirmed}}</span>

// Client script
function(spModal) {
  var c = this;
  // more control, passing options
    c.onConfirmEx = function() {
        c.confirmed = "asking";
        var warn = '<i class="fa fa-warning" aria-hidden="true"></i>';
        spModal.open({
            title: 'Delete this Thing?',
            message: warn + ' Are you <b>sure</b> you want to do that?'
        }).then(function(confirmed) {
            c.confirmed = confirmed;
        })
    }
}

open(Object options).then(fn)

Opens a modal window using the specified options.

Parameters

Returns

Example

The following code shows how to create a prompt with a label.

//HTML template
<button ng-click="c.onOpen()" class="btn btn-default">
    Prompt with label
  </button>
  <div ng-show="c.name">
    You answered <span>{{c.name}}</span>
  </div>

//Client code
function(spModal) {
  var c = this;
  c.onOpen = function() {
        //ask the user for a string
        spModal.open({
            title: 'Give me a name',
            message: 'What would you like to name it?',
            input: true,
            value: c.name
        }).then(function(name) {
            c.name = name;
        })
    }
}

Example

The following code shows how to use the custom buttons option.

//HTML template
<button ng-click="c.onAgree()" class="btn btn-default">
    Agree
  </button>
  <div ng-show="c.agree">
    You answered {{c.agree}}
  </div>

//Client script
function(spModal) {
  var c = this;
  c.onAgree = function() {
        // ask the user for a string
        // note embedded html in message
        var h = '<h4>Apple likes people to agree to lots of stuff</h4>'
        // Line feeds added to the following lines for presentation formatting.
        var m = 'Your use of Apple software or hardware products is based
on the software license and other terms and conditions in effect for the
product at the time of purchase. Your agreement to these terms is required
to install or use the product. '
        spModal.open({
            title: 'Do you agree?',
            message: h + m,
            buttons: [
                {label:'✘ ${No}', cancel: true},
                {label:'✔ ${Yes}', primary: true}
            ]
        }).then(function() {
            c.agree = 'yes';
        }, function() {
            c.agree = 'no';
        })
    }
}

Example

The following code shows how to use the embedded widget option.

//HTML template
<button ng-click="c.onWidget('widget-cool-clock')" class="btn btn-default">
    Cool Clock
  </button>

//Client script
function(spModal) {
  var c = this;
  c.onWidget = function(widgetId, widgetInput) {
        spModal.open({
            title: 'Displaying widget ' + widgetId,
            widget: widgetId,
            widgetInput: widgetInput || {}
        }).then(function(){
            console.log('widget dismissed');
        })
    }
}

prompt(String message, String default).then(fn)

Displays a prompt for user input.

Parameters

Returns

Example

//HTML template
 <button ng-click="c.onPrompt()" class="btn btn-default">
    Prompt
  </button>
  <div ng-show="c.name">
    You answered <span>{{c.name}}</span>
  </div>

// Client script
function(spModal) {
  var c = this;
  c.onPrompt = function() {
        spModal.prompt("Your name please", c.name).then(function(name) {
            c.name = name;
        })
    }
}

Version: zurich

API Reference – Client Side

ServiceNow provides client-side JavaScript APIs allowing all of you to control aspects of how ServiceNow is displayed and functions within the web browser. This reference lists available classes and methods along with parameters, descriptions, and examples to make controlling the end user experience easier.

spUtil

The spUtil API provides utility methods to perform common functions in a Service Portal widget client script.

These functions include:

• Display a notification error message. spUtil – addErrorMessage(String message)
• Display a notification info message. spUtil – addInfoMessage(String message)
• Display a trivial notification message. spUtil – addTrivialMessage(String message)
• Create a unique identifier. spUtil – createUid()
• Format a string with variables. spUtil – format(String template, Object data)
• Embed a widget model in a widget client script. spUtil – get(String widgetId Object data)
• Retrieve all headers to use for API calls. spUtil – getHeaders()
• Return the complete host domain. spUtil – getHost()
• Execute the callback with User Preference response by passing the preference name. spUtil – getPreference(String preference, Function callback)
• Return the current service portal URL information. spUtil – getURL()
• Check if the current client is a mobile device. spUtil – isMobile()
• Parse the comma-separated attributes within a specified string. spUtil – parseAttributes(String attributes)
• Watch for updates to a table or filter and returns the value from the callback function. spUtil – recordWatch(Object $scope, String table, String filter, Function callback)
• Call the server and replaces the current options and data with the server response. spUtil – refresh(Object $scope)
• Scroll to the element with the specified selector, over a specified period of time. spUtil – scrollTo(String selector, Number time)
• Update the header breadcrumbs. spUtil – setBreadCrumb(Object $scope, Array breadcrumbs)
• Set a user preference. spUtil – setPreference(String pref, String value)
• Update the search page. spUtil – setSearchPage(String searchPage)
• Update the data object on the server within a given scope. spUtil – update(Object $scope)

For additional information on widgets, see Service Portal widgets.

addErrorMessage(String message)

Displays a notification error message.

Parameters

Returns

Example

spUtil.addErrorMessage("There has been an error processing your request")

addInfoMessage(String message)

Displays a notification info message.

Parameters

Returns

Example

spUtil.addInfoMessage("Your order has been placed")

addTrivialMessage(String message)

Displays a trivial notification message.

Trivial messages disappear after a short period of time.

Parameters

Returns

Example

spUtil.addTrivialMessage("Thanks for your order")

createUid()

Create a unique identifier.

Returns

format(String template, Object data)

Formats a string that contains variables.

Use this method as an alternative to string concatenation.

Parameters

Returns

Example

spUtil.format('An error ocurred: {error} when loading {widget}', {error: '404', widget: 'sp-widget'})

'An error occurred: 404 when loading sp-widget'

get(String widgetId Object data)

Embeds a widget model in a widget client script.

The callback function returns the full widget model. For additional information on widgets, see Service Portal widgets.

Parameters

Returns

Example

Without data passed.

spUtil.get("widget-cool-clock").then(function(response) {
  c.coolClock = response;
});

Example

With data passed.

spUtil.get('pps-list-modal', {title: c.data.editAllocations,
  table: 'resource_allocation',
  queryString: 'GROUPBYuser^resource_plan=' + c.data.sysId,
  view: 'resource_portal_allocations' }).then(function(response) {
    var formModal = response;
    c.allocationListModal = response;
  });

getHeaders()

Retrieves all headers to use for API calls.

Returns

getHost()

Returns the complete host domain.

Returns

getPreference(String preference, Function callback)

Executes the callback with User Preference response by passing the preference name.

Parameters

Returns

getURL()

Returns the current service portal URL information.

Returns

isMobile()

Checks if the current client is a mobile device.

Returns

parseAttributes(String attributes)

Parses the comma-separated attributes within a specified string.

Parameters

Returns

Example

function getRefQualElements() {
  var refQualElements = [];
  if (field && field.attributes && field.attributes.indexOf('ref_qual_elements') > -1) {
    var attributes = spUtil.parseAttributes(field.attributes);
    refQualElements = attributes['ref_qual_elements'].split(';');
  }
  return refQualElements;
}

recordWatch(Object $scope, String table, String filter, Function callback)

Watches for updates to a table or filter and returns the value from the callback function.

Allows a widget developer to respond to table updates in real-time. For instance, by using recordWatch(), the Simple List widget can listen for changes to its data table. If records are added, removed, or updated, the widget updates automatically.

Note: When passing the $scope argument into the recordWatch() function, inject $scope into the parameters of your client script function.

Parameters

Returns

Example

//A simple recordWatch function.
spUtil.recordWatch($scope, "live_profile", "sys_id=" + liveProfileId);

//In a widget client script
function(spUtil, $scope) {
  /* widget controller */
  var c =this;

  // Registers a listener on the incident table with the filter active=true,
  // meaning that whenever something changes on that table with that filter,
  // the callback function is executed.
  // The callback function takes a single parameter 'response', which contains
  // the property 'data'. The 'data' property contains information about the changed record.
  spUtil.recordWatch($scope, "incident", "active=true", function(response) {

    // Returns the data inserted or updated on the table
    console.log(response.data);

    });
}

refresh(Object $scope)

Calls the server and replaces the current options and data with the server response.

Calling spUtil.refresh() is similar to calling server.refresh(). However, when you call spUtil.refresh(), you can define the $scope object.

Parameters

Returns

scrollTo(String selector, Number time)

Scrolls to the element with the specified selector, over a specified period of time.

Parameters

Returns

setBreadCrumb(Object $scope, Array breadcrumbs)

Updates the header breadcrumbs.

Parameters

Returns

setPreference(String pref, String value)

Sets a user preference.

Parameters

Returns

setSearchPage(String searchPage)

Updates the search page.

Parameters

Returns

update(Object $scope)

Updates the data object on the server within a given scope.

This method is similar to server.update(), but includes a $scope parameter that defines the scope to pass over.

Parameters

Returns

Example

The following includes a P1 widget that watches for changes to the state field and uses a filter to watch all active P1s and let the callback function determine whether to refresh the data. The data.changes property contains an array of any updated fields. If the state of any fields have changed, the data is updated in the widget.

var q = "priority=1^active=true^EQ";
spUtil.recordWatch($scope, "incident", q, function(event, data) {
   if (data.changes.includes("state")) { // only update if state was updated.
      spUtil.update($scope);
   }
});
